| INCH | SIZE | FACE | INSET | HOLE | P.C.D. | DRILL | BORE | PRICE | BIG CALIPER CLEARANCE |
|---|---|---|---|---|---|---|---|---|---|
| PG Color | |||||||||
| 18 | 8 1/2J | FACE-3 | 45 | 5 | 100 | φ29-φ15 | φ65 |
-
|
|
| FACE-3 | 45 | 5 | 114.3 | φ32-φ15 | φ73.1 |
ηθ■⊿□●
|
|||
| 9J | FACE-3 | 45 | 5 | 114.3 | φ32-φ15 | φ73.1 |
η▽θ■⊿＃△○★
|
||
| 9 1/2J | FACE-4 | 45 | 5 | 100 | φ29-φ15 | φ65 |
-
|
||
| FACE-4 | 45 | 5 | 114.3 | φ32-φ15 | φ73.1 |
ηθ■⊿□▲α●
|
|||
| FACE-4 | 22 |
η▽θ■⊿◎＃△○☆◇
|
|||||||
| FACE-4 | 35 |
η▽θ■⊿◎＃△○★◆
|
|||||||
| 10J | FACE-4 | 40 | 5 | 114.3 | φ32-φ15 | φ73.1 |
η▽θ■⊿◎＃△○★◆
|
||
| FACE-5 | 20 |
η▽θ■⊿◎＃△○☆◇
|
|||||||
| 10 1/2J | FACE-5 | 22 | 5 | 114.3 | φ32-φ15 | φ73.1 |
η▽θ■⊿◎＃△○☆◇
|
||
| FACE-5 | 15 |
η▽θ■⊿◎＃△○☆◇
|
|||||||
| 11J | FACE-5 | 15 | 5 | 114.3 | φ32-φ15 | φ73.1 |
η▽θ■⊿◎＃△○☆◇
|
Caution
- [ MARK of BIG CALIPER CLEARANCE ]
- ※Big caliper clearance marks are not suggestions for fitment.
- ・▼： IMPREZA (GDB 4POT), 86/BRZ Brembo
- ・▽： IMPREZA (GDB & GRB 4POT)
- ・θ： WRX STI
- ・η： WRX STI (6POT)
- ・■： IS, GS, RC, CROWN (210), MARK-X (3.5L)
- ・⊿： IS-F
- ・◎： RC-F
- ・＃： SILVIA
- ・△： SKYLINE (R34GT-R, CPV35, CKV36, HV37)
- ・α： SKYLINE (CKV36, HV37), FUGA (Y51)
- ・▲： SKYLINE (R34 GT-R)
- ・○： FAIRLADY Z (Z33, Z34)
- ・●： FAIRLADY Z (Z34)
- ・☆： LANCER EVO.(VII～IX, X)
- ・★： LANCER EVO.X
- ・◇： GT-R (R35/φ380, φ390 rotor)
| NCH | SIZE | FACE | INSET | HOLE | P.C.D. | DRILL | BORE | PRICE | SAMPLE FITTMENT |
|---|---|---|---|---|---|---|---|---|---|
| MM Color | |||||||||
| 18 | 8 1/2J | FACE-3 | 42 | 5 | 112 | φ32-φ15 | φ66.6 | VW GOLFV/Ⅵ/Ⅶ、AUDI TT(8J) | |
| 9J | FACE-4 | 23 | 5 | 120 | φ32-φ15 | φ72.6 | BMW M2(F87)Fr | ||
| FACE-4 | 27 | 112 | φ32-φ15 | φ66.6 | SUPRA(A90)Fr | ||||
| 9 1/2J | FACE-4 | 45 | 5 | 120 | φ32-φ15 | φ72.6 | CIVIC TYPE-R(FK-8) | ||
| FACE-4 | 38 | CIVIC TYPE-R(FK-8) | |||||||
| FACE-5 | 20 | BMW M3(E92)Fr、M4(F82)Fr,M2(F87)Fr* | |||||||
| FACE-5 | 20 | 112 | φ32-φ15 | φ66.6 | SUPRA(A90)Fr | ||||
| 10J | FACE-4 | 34 | 5 | 120 | φ32-φ15 | φ72.6 | BMW M2(F87)Rr | ||
| FACE-4 | 34 | 112 | φ32-φ15 | φ66.6 | SUPRA(A90)Rr | ||||
| 10 1/2J | FACE-5 | 30 | 5 | 120 | φ32-φ15 | φ72.6 | BMW M3(E92)Rr、M4(F82)Rr,M2(F87)Rr* | ||
| FACE-5 | 30 | 112 | φ32-φ15 | φ66.6 | SUPRA(A90)Rr |
Caution
- ・All 5H-P.C.D.112/120: Cannot fit Mercedes(GL Class, GLS Class, R550 4Matic, R350 4Matic 2012-, ML63 4Matic, S550 Plug in Hybrid, V class[W447], GLE63S 4Matic), Rolls-Royce, Bentley, Maybach(57,62), BMW X5 (7seater), BMW X5 (F15), BMW X6 (Active Hybrid), Land Rover.
- ※Fitments listed in this SAMPLE FITMENT are for reference only and do not guarantee inspection, clearance, and/or the size mandated by local authorities. Selecting sizes is by your own judgement and we recommend consulting fitments with a professional outlet.
- ※ * ：Tuner size. (Tire and or wheel may interfere or protrude from the body/fender on normal based vehicles.
Proof of lightweight design
Diamond cut machining applied to the center hole area and the rim flanges contributes to reducing the weight of the wheel, through elaborate strength analysis that identified the area that would not be affected by the machining.
In addition, the hole shape has been renewed to add two action lines for deeper and more dynamic design, which also allows attachment of a center cap. Furthermore, the flange shape has been changed under the concept of being stronger and lighter than conventional products.
https://ja-jp.facebook.com/rayswheels/videos/10159092719182980/
Racing concave
Three types of faces, Face-3 to -5, are available to fit current vehicles and settings, unlike the SAGA S-plus. The concave inclination has been designed to highlight the SAGA SL’s design the most.
Spoke sticker
The spoke sticker, synonymous with the SL Series, has been changed for the SAGA SL to three-area specification with a new logo.
It uses a proprietary sheet and has thermal resistance performance, which makes the sticker distinctive among numerous and various stickers on the market. Above all, the outline letters allowing the wheel color to show give the product a one-of-a-kind specification together with the additionally-layered coating laminate.
Knuring finish
High-grip tires which supports the high performance, high power vehicles. TE37SAGA SL employs knuring finish on its bead seat to resist slippage between the tire and wheel. It contributes to minimize the loss of traction and change in balance of tire when bigger traction occurs.
- ・Method：Forged 1pc Wheel
- ・RAYS original test：JWL+R Spec2
(Knuring finish) - ・Color：Pressed Graphite(PG)
- ・Included：Air Valve, Spoke sticker set(included)
- ・Optional：Various "VR CAP MODEL-01", EU parts set
※Please refer to the option parts tab below.
